ADINA Dynamic Analysis
ADINA 에서의 dynamic 해석
• Monitors energy variations through solution
• AUI menu: Control→Energy View (.egy)...
• Energy view during analysis or later through information stored in.egy file
• Strain energy currently for 2D and 3D solid elements
• Energy View tab in Solver UI
• Standalone: Start→Programs→ADINA System 9.2
→ADINA Structures Energy Graph
• Post-Processing
menu:Graph→Energy View
• Damping energy for stabilization should be small
Topics presented
• Introduction
• Time Integration
• Implicit Analysis
• Explicit Analysis
• Implicit vs Explicit
• Implicit - Bathe Method
• Analysis Switch
• Energy Calculations
자세한 내용 pdf 파일로 [ 자세히 보기 ]
※ 문의사항은 당사로 연락 부탁 드립니다.
